| Non-rising stem slab gate valves manufactured by Sitasia Energy are available in temperature classes L, P, R, S, T, and Uspecified in API 6A. Gate valves to be used in the 350OFor 650OF high temperature can be supplied on request.Fire-proof gate valves also can be supplied to API 6A.Gate valves manufactured by our company are available in 2000psi, 3000psi, 5000psi, 10000psi and 15000psi working pressure, material classes from AA through FF, product specification levels (PSL) from 1 through 3 and performance requirement (PR) 1.
Simple structure and renewable gate and seatassembly
One-piece and double-acting gate with long servicelife.
Both thrust bearings with large load capacity and composite rubber-plastic stem lip
packing minimize operational torque.
Bearing cap is provided with a grease cup to makeit easy to inject lubricating grease in the field.
Threaded packing gland allows removal of bearings and stem packing under line pressure.
Both the bolted bonnet and modern bonnet seal ringprovide simple structure and
reliable sealing.
The sealing surfaces of the gate and seat arehardfaced for wear and corrosion resistance.
Wave springs are installed between the body andseat and between the gate and seat.The gate and seatstill maintain a positive metal to metal seal under low pressure.
Floating gate design requests the hand wheel to bebacked off 1/4 turn after its rotation can go no further. |
